Sensing Type Through-beam
Sensing distance 5m
Sensing target Opaque materials
Min.Sensing target ≥Φ10mm
Response time ≤1ms
Light source infrared LED
Peak emission wavelength 850nm
Sensitivity adjustment Controlling emitted Sensitivity using external resistance on Control Line(3kΩ-10kΩ，adjustable)
Operation mode Light On
Indicator Power indicator(green),Operation indicator(red)
Power supply 12-24VDC
±10%（ripple P-P:≤10%）
Protection rating IP66
Cable spec. Φ3mm，3wire
Unit weight(packaged) ≈130g（≈150g）
Panel cut-out：
aperture diameter：Φ12.2
Panel thickness：1.0-2.2
